Product Information
- Global universal voltage, 100-240V AC, 50/60Hz
- Built-in remote control, ASK modulation, frequency 433.92MHz
- Built-in antenna, remote control distance >50 meters
- External dry contact interface, adjustable control method
- Three adjustable speed settings: 120 rpm/100 rpm/80 rpm, default speed 100 rpm
- Manual pull-start function can be turned on/off via remote control
- Custom stroke function: after automatic obstacle detection sets the stroke, custom switch stroke can be set via remote control
- Intermediate limit function: allows setting an intermediate limit point at any position
- Built-in Tuya smart module, supports APP intelligent network control
- Uses chips from top international brands, stable and reliable performance
- Simple and stylish exterior design, easy installation, clean and elegant
- User-friendly industrial design, convenient installation and use, safe and reliable
Curtain Motor
KYOK Smart Curtain Motors Series
KYWF Series Curtain Motor
KYWF-V1.0-53C-1.2N/ADERL Tuya Edition
Supporting app control (Tuya Smart) and remote operation.KYLX-V1.0-53C-1.2N-EN/ADERL Offline Voice Edition
Featuring English offline voice control and wireless remote functionality.KY00-V1.0-53C-1.2N/ADERL Basic Edition
RF remote-controlled model for essential curtain automation.
DT82 Series Curtain Motor
DT82-Li Battery Edition
4-cell lithium battery powered, delivering up to 6 months of operation per charge.DT82-TV High-voltage Central Control Edition
Supports scene panel control and wireless remote operation (hardwired AC power).DT82-TN Low-voltage Central Control Edition
Wireless remote-controlled model (low-voltage DC power system).
DT52EN/N Series Curtain Motor
DT52EN/N Series Smart Curtain Motor
Low-voltage control model supporting wireless remote operation.
This high-performance 220V AC motor delivers exceptional quiet operation at ≤30dB while generating 1.2N·m torque for smooth curtain movement. With a robust 100kg load capacity and 75W rated power, it effortlessly handles curtains spanning 0.5-12m widths at 112R/min (20cm/s) speed. Designed for reliability in diverse environments, it operates within -10℃~50℃ temperatures and features IP20 protection. The 3-core power cable ensures stable connectivity, while its ultra-efficient design (0.34A current draw) minimizes energy consumption. Unique in its class, this motor supports intermittent operation cycles under 4 minutes – perfect for high-frequency residential and commercial applications requiring whisper-quiet, maintenance-free performance.
DT10LEU Series Curtain Motor
DT10LEU-1.2N:
Low-voltage control model with wireless remote operation, featuring a lithium battery that delivers 6 months of operation per charge.
| Motor Specifications: DT10LEU-1.2N | |
|---|---|
| Motor model | DT10LEU-1.2N |
| Noise level | ≤30dB |
| Rated torque | 1.2N.m |
| Rated voltage | DC5V |
| Rated current | 1.0A |
| Rated power | 6W |
| Width range | 0.5m - 12m |
| Wireless frequency | 50Hz |
| Operating speed | 20cm/s |
| Protection level | IP40 |
| Continuous operation | ＜4 min |
| Operating temperature | -10℃~50℃ |
| Lithium battery | Change once and use for half a year |
Control Option
Remote Control
Simple and reliable—operate your curtain motors effortlessly with a traditional handheld remote.
Voice & WiFi Control
Smart convenience—connect to WiFi for app control and enjoy hands-free operation via Alexa or Google Assistant.
Rechargeable Battery Motor
Cordless and eco-friendly—built-in lithium battery supports long-lasting performance and easy recharging.
Matter-Compatible Motor
Future-ready smart integration—supports Matter protocol for universal smart home connectivity across platforms like Apple HomeKit, Google Home, and Amazon Alexa.
Get a FREE Quote
For a FREE QUOTE or product information on any curtain furnishing product, please send us a short note and we will respond within 24 hours!
NEED HELP?
Motorized Curtains FAQs
Our standard MOQ is 200 units per model for bulk orders. For OEM/ODM projects requiring custom designs or private labeling, MOQ starts from 500 units (negotiable based on motor specifications and fabric complexity). Contact our team for flexible MOQ solutions tailored to your market needs.
All systems carry CE, RoHS, BSCI, and ISO 9001 certifications. For full certification documents, visit our Compliance Certificates Page.
Yes, absolutely! Our motorized curtains are designed to operate reliably without Wi-Fi.
Remote Control: You can always use the included physical remote control to open and close your curtains.
Manual Operation: For added convenience or in case of power loss, you can also gently pull on the curtain fabric to manually open or close them, just like traditional curtains.
Offline Functionality: The core motor operation is independent of your home network. This means even if your Wi-Fi is down or disconnected, or if there’s a temporary power outage (provided the battery backup is active or power returns), you retain full control over your curtains via the remote or manual operation.
Enjoy peace of mind knowing your curtains work anytime, anywhere, online or offline!
Absolutely! Our lithium battery-powered motors utilize 4 industrial-grade 18650 lithium batteries. A full charge provides up to 6 months of operation. The battery features a BMS (Battery Management System) with triple protection against overcharging, over-discharging, and short circuits. Even during a home power failure, you can still control your curtains via remote or smartphone app.
Yes! We provide step-by-step guides! For complex setups Explore our DIY guides or contact our installers.
Prices vary based on window size, fabric choice, motor type (battery vs. hardwired), and smart features. Request a free quote on our site for accurate pricing tailored to your needs.
Yes! Most systems support major platforms via hubs or native apps. Look for Matter/Thread compatibility for future-proofing. We provide setup guides for popular ecosystems. Contact us for specific compatibility checks with your devices.
Our premium systems use ultra-quiet motors (<35 dB) tested for 10,000+ cycles. Noise levels are comparable to a whisper. Reliability is ensured through durable materials, overload protection, and 2-5 year warranties. Regular maintenance is minimal – just occasional dusting.
